Specification

GPS Chipset

Ublox

Frequency

L1, 1575.42 MHz

C/A Code

1.023MHz chip rate

Channels

50channel all-in-view tracking

Tracking Sensitivity

-160dBm

Support

DGPS[WAAS, EGNOSandMSAS]

Acquisition Time

Hot Start

1 sec., average (with ephemeris and almanac valid)

Warm Start

30sec., average (with almanac but without ephemeris)

Cold Start

39sec., average (neither almanac nor ephemeris)

Reacquisition

0.1 sec,. average (interruption recovery time)

Protocol

GPS Output data

NMEA0183 protocol

GPS Transfer rate

9600 / 4800

Dynamic Condition

Acceleration

Less than 4G

Altitude

18,000 meters max.

Coordinate

WGS-84

Drifting

<0.02s/m

Velocity

500meters/ sec. max.

Interface

USB / PS2

Dimension

2m

49*38*16mm (L x W x H)

Temperature

Operating

-30 ~ +80

Storage

-30 ~ +80

Humidity

Up to 95% non-condensing
