Item

Specifications

Antenna

Center Frequency

1575.42+-3MHz

Band Width

CF+-5MHz

Polarization

RHCP

Gain

1dBic(Zenith)

V.S.W.R

＜1.5

Impendance

50ohm

Dimension

15*15*4mm

LNA

Gain

28+-2dB

Noise Figure

＜2

Ex-band Attenuation

30dB@CF±40MHz

Supply Voltage

3-5V DC

Current Consumption

5~10mA

V.S.W.R

＜2.0（min）

Mechanical

Cable

RF1.13 or others

Connector

IPEX or others

Environmental

Operating Temperature

-40-+85 degree

Relative Humidity

Up to 75%

Vibration

10 to 55Hz with 1.5mm amplitude 2hours

Environmentally Friendly

ROHS Compliant
